Model: 88.11.1.13.92550

Rated Voltage: 12V
Power: 10W
Lamp Holder: G4
Mounting Size: 30*70(mm)
Material: Stainless steel

Certificate: UL、CSA、TUV、CE、ROHS、SAA

Drawings: Click Download
  • Rated temperature T550 (continuous use)
  • Oven lamps with halogen mains voltage lamps specify the upper limit and nominal voltage
  • Terminals (in mm) for electrical connection and/or grounding indication (in this product, 6.3*0.8mm)
  • Material thickness indication in millimeters (1.0-1.2mm in this product)
Contact us for details

Oven Light 10W G4 12V

Description:

This oven light bulb is suitable for ovens and microwave ovens. Our common oven lamp installation dimensions are 30*70mm, 55*70mm, φ35.5mm, φ48mm, φ67mm. The lampshade type, bulb type, base material, etc. can be customized according to customer needs.

Features:
1. High temperature resistance, low working temperature, good heat dissipation, not easy to cause aging and yellowing of the lampshade
2. High strength and good light transmittance
3. Good heat dissipation performance and long service life
4. Low operating voltage during operation, safe and reliable
5. The bulb is small in size and easy to install
6. High color rendering index
7. Energy saving and environmental protection

8. Quality assurance, passed multiple international certifications



Related Product Parameters

Product Model

Power

Wires

Temperature

Fixing

Bulb Type

Voltage

Lens Material

Lampholder Material

Reflector

88.11.1.13.43110

5W

10362/18#

Max, 250

Screw fixing

G4

12V

Borosilicate glass 550

Ceramics

Stainless Steel

88.11.1.13.43150

5W

5128/18#

Max, 450

88.11.1.13.43210

10W

10362/18#

Max, 250

88.11.1.13.43250

10W

5128/18#

Max, 450

88.11.1.13.43410

20W

10362/18#

Max, 250

88.11.1.13.43450

20W

5128/18#

Max, 450

88.11.1.13.51510

25W

10362/18#

Max, 250

G5.3

110V

88.11.1.13.51550

25W

5128/18#

Max, 450

110V

88.11.1.13.52510

25W

10362/18#

Max, 250

230V

88.11.1.13.52550

25W

5128/18#

Max, 450

230V

88.11.1.13.53210

10 W

10362/18#

Max, 250

12V

88.11.1.13.53450

20W

5128/18#

Max, 450

12V




Note: Due to the special products of our company, different specifications will have different prices, so the exact price cannot be determined. If you are interested in buying, please contact our customer service staff, thank you for your cooperation!

Brand:

J&V

Product type:

Oven lamp

Model:

88.11.1.13.92550

Mounting size:

30*70mm

Installation way:

Screw fixation

Bulb:

G4

Power:

10W

Voltage:

12V

Housing material:

SUS

Lamp Holder Material:

Ceramic lamp holder 88.11

Shade Material:

Stainless steel

Lampshade material:

13# plane high borosilicate glass

Wiring type:

5128

Safety:

ULCSATUVCEROHSSAA
