Model: 88.32.6.63.11308 right angle

Rated Voltage: 230-240V
Power: 15W
Lamp Holder: 88.32
Mounting Size: φ48mm
Material: Stainless steel

Certificate: TUV、CE、ROHS

Drawings: Click Download
  • The oven lamp is equipped with a special Edison spiral lamp, which specifies the upper limit and nominal voltage
  • Light distribution curve
  • Terminals (in mm) for electrical connection and/or grounding indication (in this product, 6.3*0.8mm)
  • Material thickness indication in millimeters (1.0-1.2mm in this product)
Contact us for details

Round Oven Lamp 15W

Description:

This oven lamp bulb is suitable for ovens and microwave ovens. Our common oven lamp installation dimensions are 30*70mm, 55*70mm, φ35.5mm, φ48mm, φ67mm. The lampshade type, bulb type, base material, etc. can be customized according to customer needs.

Features:
1. High temperature resistance, low working temperature, good heat dissipation, not easy to cause aging and yellowing of the lampshade
2. High strength and good light transmittance
3. Good heat dissipation performance and long service life
4. Low operating voltage during operation, safe and reliable
5. The bulb is small in size and easy to install
6. High color rendering index
7. Energy saving and environmental protection

8. Quality assurance, passed multiple international certifications

Brand:

J&V

Product type:

Oven lamp

Model:

88.32.6.63.11308 right angle

Mounting size:

φ48mm

Bulb:

E14 230-240V 15W

Lampshade:

Medium round calcium carbonate lampshade can withstand temperature of 350℃, high borosilicate lampshade can withstand temperature of 550℃

Terminal:

250 horizontal male terminal (6.3x0.8)

Installation way:

Threaded

Lamp holder:

Ceramic lamp holder 88.32

Housing material:

Stainless steel

Safety:

TUVCEROHS
